Features :-
Display Calorific Value in Calorie/gram or other internationally accepted units.
Extensive Diagnostic Function for problem investigation
Integrated and closed loop water handling system
“auto shut off” of the filling valve after attaining of requisite pressure in the bomb.
Automatic compensation of calorific value to get ready made GCV in Cal/gm. or Kcal/Kg.
Double stage SS gas regulators with safety valve
Branded on line UPS with 60 minutes power back up
Laser Printer with all accessories & software and compatible with PC
Test Certificate of Gas, Hydro Test Certificate of Cylinder & Filling Penmission
Material Producer as per ISO 17034.
Technical Data :-
Controller : Microprocessor based/PC operated
Standard : ASTM: D 5865 & IS 1350 Part II
Principle : Isoperibol Calorimetric principle.
Power : 220V, 50Hz single phase AC
Sample Weight : (0.6 to 1.4) gram
CV Range : Upto 8,000 Kcal/Kg for 1 gram of sample.
CV Resolution : 0.1 Calorie/gram
Precision : 0.05 % RSD on Benzoic acid for GCV
Temperature Resolution : 0.0001 degree centigrade
Analysis Time : Maximum 15 minutes
Balance analysis sample : 0.0001 gram
Connecting tube : 2 meter length.
Cylinder : Filled Oxygen 47 Litre
Analytical Balance :-
capacity: 0-220 gram
Least Count : 0.1 mg,
repeatability: 0.1mg,
Automatic internal calibration
Display : clear digital display with backlight.
PC
PC : Branded PC for running of the instrument & Laser Printer
Make: Pcs
Central Processing Unit (CPU) : INTEL Core i-7
Memory: Random Access
Memory (RAM): 8 GigaByte , Double Data Rate 3(DDR3)
Hard Disk Drive (HDD) : 500 GigaByte (GB)
Monitor: 19″ Light Emitting Diode (LED)
Key Board & Mouse: Universal Serial Bus (USB) optical
Ports: 3 Universal Serial Bus (USB) ports
Latest antivirus software and latest licensed windows Operating System software
Accessory :-
Branded PC
Printer
Fuse Wire – 10,000 Numbers
O-ring
Combustion Crucible -20 Nos with each set
Tool Kit for the Instrument – 01Set per instrument.
Bomb charging station per each set
Bomb wiping cloth per each set
Dust Cover-01 Number per each set
Instruction Manual
Warranty Card
