Specification :-
Type : Electronic lift
Temperature range : Ambient to 220°C
Heating power : 1500W.
Operating voltage : 220 – 240 V at 50/60 HZ
Display : LCD display
Temperature deviation : at 2°C.
Rotation speed : adjustment 20 to 280 RPM.
Features :-
– Cordless power supply allows emptying and refilling of water bath without unplugging.
– LCD display indicates set and actual values of heating bath temperature, rotation speed, and lift height adjustment.
– Auto lift from heating bath at the time of power failure
– Accommodate flask size from 50 ml to 5000 ml.
– Multifunction comb clip
– A plastic coating on glass (P+G)
– Condensate trap to trap external moisture formed on condenser
– Provided with flask of 1000 ml each flask with flask joint SJ29/32
– Evaporation flask feeding via stopcock.
– Rust free body material
– Infrared bi-directional communication between heating bath and rotary evaporator
Vacuum Pump :
Operating voltage : 220 – 240 V at 50/60 HZ
Membrane Pump : Two stage PTFE with window heads
Flow rate : 1.8 m3/hr.
Vacuum : 5 mbar
Vacuum Controller :
Display : Touch screen
Operating mode : Manual, Timer, Continuous, Drying etc.
Features :-
– Rotary knob / button Allows in both ways
– Built in solvent library (extended version: 60 Solvents).
– Allows to add and bookmark individual solvents
– Distillation process starts directly after choosing solvent from the library.
– Offers push notifications and live view of all process parameters on mobile devices.
– All process are graphically displayed to facilitate the supervision of distillation
– Data recording Set for further analysis and traceability purpose.
– Enables to record all process parameters continuously
Accessories :-
– Cord & plug
– Warranty Card
– Instruction Manual
